Delta 31-481 26 in. Dual Drum Sander

SKU 31-481
Item In Stock
$1,785.00 $3,570.00 50%
Description
Features & Specs
Delta 31-481 26 in. Dual Drum Sander
  • Industrial 3 HP, 230V, 60 Hz, 1 Phase Main Motor with magnetic controls;
  • 1/6 HP, 1 phase, variable speed feed belt motor with feed speeds from 3 FPM to 20 FPM; drum speed 1,550 RPM
  • Increased capacity allows for sanding material up to 12 1/4 in. deep x 25 1/2 in. wide
  • Independent adjustable rear drum offers one pass sanding capability using 2 grits, reducing processing time
  • Rear roller adjustment dials ensure rear drum is level
  • Heavy duty steel frame design with superior finish for long-lasting durability
  • Latching top door provides direct access to dual drums for ease in sanding wrap changes
  • Toolless drum wrap tensioning clamps make installation and removal of sanding strips easy, requiring less downtime
  • Magnetic on/off main motor switch; removable key switch for variable speed feed belt motor
  • Two 4 in. dust ports for efficient dust collection requiring a total of only 600 CFM
  • Includes (2) 4 in. integral dust ports, feed belt, (2) sanding drums, (1) 80 grit and (1) 120 grit sanding strips
  • CSA Listed
    Specifications:
  • Main Motor: 3 HP, 230V, 60 Hz TEFC, 1 Phase
  • Feed Motor: 1/6 HP, 1 Phase, Variable Speed
  • Speeds: 1,550 RPM Drums; 3 to 20 FPM Feed Belt
  • Sanding Capacity: 12 1/4 in. Thick x 25 1/2 in. Wide
  • Minimum Sanding Thickness: 1/4 in.
  • Minimum Length of Unbutted Stock: 6 in.
  • Drums: 5 in. x 26 in., Aluminum
  • Sanding Strip Size: 5 1/8 in. x 92 1/2 in.
  • Dimensions (Assembled): 31 in. x 46 in. x 53 in.
  • Base Dimension for Mobile Base: 17 3/4 in. x 43 in.
  • Shipping Dimensions: 48.3 in. x 32.68 in. x 51.97 in.
  • Weight: 418 lbs.
  • Shipping Weight: 484 lbs.
