Porter Cable Router 7539 Porter Cable Speedmatic 3-1/4 Peak HP Five-Speed Plunge Router
15 Amps, AC only
Electronic five-speed with soft start 10,000, 13,000, 16,000, 19,000, 21,000 RPM
Maintains constant speed under load
1/2" collet
Auto-release collet system ends "frozen" bits
Unique design puts bottom bearing closer to work for minimum bit run-out and vibration
3" plunge range with fully enclosed springs
Depth rod, and 6 position step turret
Precision machined aluminum motor housing & base
100% sealed ball bearings
Contents: Router motor, base, 1/2" collet #42950, collet wrench #42596 and operating manual
SPECIFICATIONS
MOTOR:
- Power: 120 VAC, 60 HZ
- Peak Horsepower: 3-1/4
- Amps: 15
- Speed: 5 speed soft-start 10,000, 13,000, 16,000, 19,000, and 21,000
COLLETS:
- Standard: 1/2"
- Available: 1/4" & 3/8"
SIZE:
- Height: 13-1/8"
- Weight: 17-1/4 lbs
Porter Cable Routers 7518 & 7539 Owner's Manual
CA Prop 65 WARNING: Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance know to the State of California to cause cancer. Avoid inhaling wood dust or use dust mask or other safeguards for personal protection.
