Sherline Mill 5400A Sherline Milling Machine Package
SKU: 5400A
Sherline Mill Sherline Milling Package 5400A includes 5400 milling machine
3013 step block hold-down set
3020 5/32" hex T-driver
3021 3-pc. center drill set
3052 fly cutter
3060 3-pc. mill collet set
3072 Jacobs 1/4" tailstock drill chuck w/ key, #0 Morse arbor, #1 Morse arbor with drawbolt
3079 3/8" end mill holder
7400 6-pc. 3/8" shank double ended end mill set
3551 milling vise
5327 Sherline Shop Guide book
(Metric P/N 5100A)
Sherline's most popular mill. It comes equipped with all of Sherline’s standard features upgraded to include a
Laser engraved 12" (305mm) solid aluminum base for 2" or additional Y-axis travel
Laser engraved scales on the table and base
2-1/2" (63mm) adjustable “zero” handwheel on the Z-axis
2" (51mm) adjustable “zero” handwheels on the X- and Y-axes
1297 mill headstock spacer to provide more throat distance
3072 1/4" drill chuck and drawbolt
Precision machined dovetailed slides with adjustable gibs
Permanently lubricated spindle bearings
Adjustable preload anti-backlash feed screws
High-torque 90 VDC motor with electronic speed control. Speed is continuously variable from 70 to 2800 RPM without gear or belt changes.
A second pulley position is also available to provide extra torque at low RPM if needed.
Many other features found only on the best commercial machines.
feeds calibrated in .001" increments,
a high-torque DC motor with variable speed control. The
speed control is internally equipped with a converter that automatically adjusts between inputs of 100 VAC to 240 VAC, 50-60 Hz. without loss of torque
Speed is continuously variable from 70 to 2800 RPM without gear or belt changes.
A second pulley position is available for providing additional torque at low RPM
