Sherline Mill 2000A Sherline Milling Machine (2000 Shown)

SKU: 2000A

100% Secure Shopping
Your Price: $1,178.00
Qty:
Sherline Milling Package Model # 2000A includes 2000 milling machine

  • 3013 step block hold-down set
  • 3020 5/32" hex T-driver
  • 3021 3-pc. center drill set
  • 3052 fly cutter
  • 3060 3-pc. mill collet set
  • 3079 3/8" end mill holder
  • 7400 6-pc. 3/8" shank double ended end mill set
  • 3551 milling vise
  • 5327 Sherline Shop Guide book

    Standard Equipment:
  • Laser engraved 14" solid aluminum base for 2" or additional Y-axis travel
  • Laser engraved scales on the table and base
  • 2-1/2" (63mm) adjustable “zero” handwheel on the Z-axis
  • 2" (51mm) adjustable “zero” handwheels on the X- and Y-axes
  • 3072 1/4" drill chuck and drawbolt
  • Precision machined dovetailed slides with adjustable gibs
  • Permanently lubricated spindle bearings
  • Adjustable preload anti-backlash feed screws
  • High-torque 90 VDC motor with electronic speed control. Speed is continuously variable from 70 to 2800 RPM without gear or belt changes.
  • A second pulley position is also available to provide extra torque at low RPM if needed.
    A modified rotary column attachment allows the Z-axis column to tilt from side to side up to 90°. A laser engraved angle scale makes setting the tilt angle easy. As on the rotary column, a clamping ring design locks the column securely at the desired angle. On the back side of this special rotary column attachment is a knuckle that allows the top of the Z-axis column to be tilted either toward or away from the operator. Laser engraved scales indicate movement up to 90° in either direction on this axis.

    In addition to the side-to-side rotary tilt movement, the new column base offers a center pivot lock that allows the ram to be moved both in and out as well as swung from side to side. In/out travel is 5.50" and side-to-side motion is indicated by laser engraved scales showing up to 90° of movement either way. These four movements are in addition to the standard mill’s X-, Y-, Z-axis travel and headstock rotation movement, giving a total of eight directions of motion or tilt. This much versatility puts the Sherline model 2000 mill in a class by itself in this size range. It is a fully functional shop mill that fits on a tabletop and stores on a closet shelf. When used with accessories like the tilting angle table and rotary table, the machining possibilities of the mill are limited only by part size and the extent of your imagination

    The 2000-series mill base has been extended an additional 2" over the Model 5400/5410, extending the Y-axis travel to 7.0" (178mm). This was done to accommodate the pivoting mechanisms and to take advantage of the increased arm movements. Like the deluxe Model 5400/5410 mills, all handwheels are resettable to zero at any time.

    The 8-direction mill includes the same laser engraved scales on the base and table as the 5400-series deluxe mill package. Also included is a 1/4" Jacobs drill chuck and key. (The headstock spacer block is not included on the 2000-series mill, as the ram travel makes it unnecessary.)

    All Sherline mills feature precision machined dovetailed slides with adjustable gibs, permanently lubricated spindle bearings, adjustable preload anti-backlash feed screws and a high-torque 90 VDC motor with electronic speed control. Speed is continuously variable from 70 to 2800 RPM without gear or belt changes. A second pulley position is also available to provide extra torque at low RPM if needed.
