Jet 708320 JWS-22CS, 1-1/2HP Shaper, 1Ph 115/230V, 1/2" and 3/4" Spindle

Jet 708320  JWS-22CS, 1-1/2HP Shaper, 1Ph 115/230V, 1/2" and 3/4" Spindle 708320
Jet 708320 JWS-22CS, 1-1/2HP Shaper, 1Ph 115/230V, 1/2" and 3/4" Spindle

Additional Images

Jet 708320  JWS-22CS, 1-1/2HP Shaper, 1Ph 115/230V, 1/2" and 3/4" Spindle 708320 Jet 708320 JWS-22CS, 1-1/2HP Shaper, 1Ph 115/230V, 1/2" and 3/4" Spindle
SKU 708320
Item In Stock
$1,119.99 $1,280.00 13%
Description
Features & Specs
If you're looking for a space-saving shaper for your shop, the new JET JWS-22CS Shaper is what you need. This compact powerhouse features a 7000 and 9000 RPM reversing 1-1/2HP motor. The large 22-3/8" x 18-1/8" precision ground cast iron table provides a large, durable, work area. Safe, easy cutter set up is assisted by a positive detent spindle lock. The independent left and right fences feature micro-adjustment, and a built in 4” dust port. If you feel you just don’t have the space, the nominal 23" x 25" footprint of this workhorse is sure to change your mind. Put the new JET JWS-22CS Shaper in your shop today, you'll know why JET products are "Built Better to Build Better."
  • Starting Pins for irregular shaping
  • Forward/reverse switch for left and right hand operation
  • Two reversible spindle speeds lets you select the best speed and torque for different cutter diameters
  • Independent left and right fences feature micro-adjustment and have zero-clearance capability
  • Extra-large handwheel is conveniently located for fast, easy and accurate spindle height adjustments
  • Positive detent spindle lock allows safer, easy cutter set-up
  • 4" dust port connects to your collection system to keep your workplace dust and debris-free
  • Fully enclosed, heavy-duty steel stand has a removable cover for easy motor access
  • 1/2" and 3/4" interchangeable spindles and router bit collets for use with shaper cutter and router bits
  • Powerful 1-1/2HP motor delivers dependable power, even on heavy jobs
  • 22-1/4" x 18-1/8" solid cast iron table provides a durable work area
  • Two adjustable work hold-downs to secure your work while shaping

    Specifications:
  • Spindle Speed (RPM) 7000/9000
  • Maximum Spindle Diameter (In.) 1/2, 3/4
  • Spindles Included Yes
  • Spindle Size Under Nut (In.) 1/2 (2-1/2), 3/4 (2-15/16)
  • Spindle Travel (In.) 1-7/16
  • Router Bit Collet Included 1/4, 1/2
  • Table Opening Diameter (In.) 5-1/4
  • Table Insert Opening Diameter (In.) 1-5/8, 3-1/4
  • Table Size (L x W) (In.) 22-1/4 x 18-1/8
  • Table T-Slot (In.) 3/4 x 3/8
  • Table Height from Floor (In.) 33-1/2
  • Fence Size (L x H) (In.) 10 x 3-1/8
  • Dust Port Outside Diameter (In.) 4
  • Motor Power (HP) 1-1/2
  • Motor Phase (PH) 1
  • Motor Voltage (V.) 115/230
  • Prewired Voltage (V.) 115
  • Motor Amps 12/6
  • Weight 211
